◆食品特征 Product features(請從上到下瀏(liu)覽記錄多大(da)量案例分析照片視頻(pin)僅供參考資料)
噴砂機主要用于電鍍、噴漆、噴涂等所有被覆蓋加工前噴砂處理;舊樣翻新清洗;金屬制品及塑膠、水晶、玻璃等表面痕跡消除,啞光霧面處理,使產品表面提升檔次;機加工零件微小毛刺去除;增加金屬件表面硬度,消除應力如彈簧、機加工刀具等;金屬制品及非金屬制品表面刻蝕圖案、文字及防滑處理,如大理石、印章、手柄防滑等。本機應用范圍:適用于大量中小型一般工件及高硬度工件的快速噴砂。如發動機配件、閥門、熱處理工件等。該機型設計新穎,結構科學合理,操作方便,加工性能優越;噴砂速度快,撞擊點深。
Features: Sandblasting machine is mainly used in electroplating, paint, coating area to-be-covered before piating; Old way of refurbished cleaning; Metal products and plastic, crystal, glass surface trace eliminate scattered, dumb, surface process to enhance the grade of the product's surface; Machining parts tiny burrs purify; Increase the metal surface hardness, eliminate stress such as spring, mechanical cutters, etc.; Metal and non-metai products surface etching pattern, writing and prevent slippery processing, such as marble, seals, and handle prevent slippery, etc. The machine is applied the range: applicable to small and medium-sized general of workpiece and high hardness workpieces quickly sandblasting. Such as engine fittings, valves, heat treatment workpiece, etc. This machine has novel, scientific design and reasonable structure, convenient operation, processing superior performance; Gush arenaceous speed, the impact point at deep.
◆適合使用范圍 Applicable scope
光學五(wu)金(jin)電器(qi)類,ABS材(cai)料(liao),亞(ya)克力面板,硅膠(jiao)模具(ju)。特重(zhong)型零(ling)部(bu)件(jian)、成分件(jian)、不飽和樹脂等零(ling)部(bu)件(jian)或加工(gong)過程品噴砂。
Applicable scope: electronic hardware class, ABS plastic, acrylic, resin, workpiece or handicraft sandblasting
◆一般系統參數指標 Main technical parameters供(gong)考生準確與銷售聯(lian)系起來
|
機設備規格(ge)型號 Model |
STR-9070 |
STR-9080 |
STR-1010 |
STR-1212 |
|
辦公艙的尺寸(cun) Internal size(mm) |
900×700×790 |
900×800×700 |
1000×1000×670 |
1180×1180×980 |
|
整體長寬(kuan)高(gao) Complete machine size(mm) |
900×700×1780 |
950×850×1720 |
1000×1000×2100 |
1200×1200×2580 |
|
除塵處(chu)理箱盡寸 Dedust box sizes(mm) |
600×600×1680 |
600×600×1680 |
600×600×1680 |
800×800×1780 |
|
電原 Power |
220V 50Hz |
220V 50Hz |
220V 50Hz |
220V 50Hz |
|
系統照明設(she)備燈 Machine floodlight |
220V 20W 能效燈 |
220V 20W 節(jie)省燈 |
220V 20W 低碳燈(deng) |
220V 20W 高效(xiao)燈 |
|
剝離 器(qi)伺服(fu)電機 Separator motor |
220V 50Hz 0.55-3KW |
220V 50Hz 0.55 |
220V 50Hz 0.55-3KW |
220V 50Hz 0.55-3KW |
|
離(li)心分離(li)設備新風量 Separator air volume |
8.5m3/min |
8.5m3/min |
8.5m3/min |
8.5m3/min |
|
壓解廢氣源(yuan) Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
服務(wu)器凈重 Weight |
380kg |
380kg |
400kg |
380kg |
